The advancedest driving gears are adopted not only toextend the use life but also to make noise lower.The gearsare made in special CrMo steel by hardening treatmentand are made according with gear precision of JISI first-class.Therefore,the harmful disturbances to produets fromgears are avoided.
The transported air is clean and is any oil-dust free oillubrication is not needed in casing and the structure designprerent the bearing oiland gear oil from entering thecasing.
The helical construction uses the stator helical methodthat the screen lines of casing at the suction and dischargesides are cut to a helical shape,and the triangle suctionand discharge port formed by a straight line of the rotortop is to be opened and closed gradually.Therefore,the suction and discharge ports of this typeis not opened or closed at moments,which makes theseblowers have an only limited operation sound and almostfree from pulsations from discharge.
The rotors are three-lobe straight type,so that therotors can not interfere with each other,resulting fromminor displacements in the thrust direction as in thehelical type. Therefore,the clearance between the rotorsshould be assured in the profile direction only and thusthere is no necessity of an excessive clearance on accountof displacements in the thrust direction as in case of therotor helical type.From such reasons,these blowers have avery high efficiency,in comparison with the rotor helicaltype of same dimensions.
With the establishment of quality management systemand manufacture management system,the aims of partsexchanging,less production cost and rapid delivery arerealized.The blowers of right quantity are keeped in stockto make delivery in time.
Character
Apply super gears to guarantee long life running with lower noise level.
Newly designed inlet & outlet bore profile.
No oil delivery
Specification
Flow: 0.6m3～90m3/min;
Pressure: Rise: 9.8～78.4kPa.
Application:
Widely used in waste water treatment, pneumatic conveying, vacuum packing, aquaculture and etc. diverse industries.
SHANDONG ZHANGHUANG MACHINERY INDUSTRY CO.,LTD is a joint venture invested by SHANDONG PROVINCE ZHANGQIU BLOWER WORKS.TAIKO KIKAI INDUSTRIES CO.,LTD.
SHANDONG ZHANGHUANG MACHINERY INDUSTRY CO.,LTD is established depending on the support from China Machinery Industry Ministry, China National General Machinery Engineering corp.and from government responsible department at different levels.
The joint venture now has accumulative total investment of USD 6,260,000, registered capital of USD 4,460,000.The investment proportion of China is 40%, proportion of Japan is 60%.
The main products Type SSR Blowers are new three-lobe roots blowers developed by TAIKO KIKAI INDUSTRIES CO.,LTD. The blowers flow capacity is from 0.6m/min to 90m/min, pressure rise is from 9.8kPa to78. 4kPa. The three- lobe Type Roots Blowers have22models, 200specifications, their remarkable features are little outline,light weight, full flow capacity, low noise and reliable operation. The products are mainly used in sewage treatment,pneumatic systems,vacuum packing and aquatic farming.
The corporation follows the policy of quality first and making user satisfaction to produce and manage has established quality guarantee system of design, development,assembling and service according to ISO9001 and passed the evaluation of China Quality certification Center For Import And Export Commodities in December, 1997.Since 1996, the products have got user's trust because of its reasonable price, reliable quality and good service. At present,our products have the absolute predominance in sewage treatment, foodstuff with a market share of 85%. Our products are being saled in China.
