High CFM Blower
The high cfm blower unit was newly developed by our company, rotary blower, inletsilencer(including air filter), outlet silencer, relief valve, pressure gauge, check valve, fiexible joint, vibration isolator areintegrated, The rotary blower in the ZMR series unit adopts the RR series blower with two lobes which technology isfrom Japan. The ZMH series compact rotary blower unit adopts the 3H series rotary blower with three lobes which wasdeveloped by our company and has several patents.
A wide range of capacity and pressure is available.Capacity 0.45~100.6m'/min;Pressure 9.8~98kPa.Noise is low.
Noise-lowing profile and structure are applied, gear accuracy is the fifth class, bearings areorted, and main parts are NC machined. So, the blower can run for a long time reliably.
Low vibration and low noise due to accurate dynamic balance.The air pulsation is low and runs smoothly.
The transported air is clean and free of oil and dust. Oil lubrication is not needed in the casing, special structure isgned to prevent the bearing oil and gear oil entering the casing.
Simple structure, little outline, light weight.
Installation is convenient and not needing anchor bolts.
ZL Series Roots Blowers and Roots Vacuum Pumps are newly designed national joint products. Since our company began production in 1987, we have accumulated more than twenty years of experience. Based on market feedback and our extensive manufacturing expertise, we have carried out multiple technical upgrades to the products. With significant structural improvements, some models have been upgraded to the ZL Series Roots Blowers and Roots Vacuum Pumps.
Through years of continuous innovation, our L and ZL Series Roots Blowers and Roots Vacuum Pumps now feature more reasonable structures, superior performance, and higher operational reliability. They are fully capable of meeting the requirements of various working conditions and handling different media, thus forming distinctive product characteristics.
Main Technical Specifications:
Air Volume: 13.7 ~ 753 m³/min
Pressure Rise: 9.8 ~ 68.6 kPa
Main Applications:
Widely used in industries such as electric power, petrochemicals, fertilizers, steel, metallurgy, oxygen production, cement, food, textiles, papermaking, dust removal and back-blowing, aquaculture, wastewater treatment, pneumatic conveying, and many other fields.
SSR-300HB and SSR-350HB THREE LOBE ROOTS BLOWER MAIN FEATURES
SSR-300HB and SSR-350HB series were the big size bore Roots Blower that based on SSR series and reference the technical from TAIKO KIKAI INDUSTRIES CO. LD to development The impeller and bearing have special design. so the blower will have high efficiency and stable performance. The rotary impeller use the advanced-production crafts of "FOUR AXIS MOVED TOGETHER" on the MC, it can ensure production accuracy and need not repair&maintain, achieve the impeller assembly can be swap.
